| 產(chǎn)品編號 NO.of product | 溝槽尺寸（dimension of slot） | O型圈（O-type ring） GB3452.1-1992 d1×d2 | |||||
| D外徑 outer diameter/OD | d內(nèi)徑 inner diameter/ID | B | L | Rmax | E直徑間隙 diameter gap | ||
| JD-24-16 | 16 | 8.5 | 3.75 | 3.2 | 0.5 | 0.85-0.5 | 8.5×2.65 |
| JD-24-18 | 18 | 10.5 | 10.5×2.65 | ||||
| JD-24-20 | 20 | 12.5 | 12.5×2.65 | ||||
| JD-24-22 | 22 | 14.5 | 14×2.65 | ||||
| JD-24-25 | 25 | 17.5 | 17×2.65 | ||||
| JD-24-28 | 28 | 20.5 | 20×2.65 | ||||
| JD-24-30 | 30 | 22.5 | 21.2×2.65 | ||||
| JD-24-32 | 32 | 24.5 | 23.6×2.65 | ||||
| JD-24-35 | 35 | 27.5 | 26.5×2.65 | ||||
| JD-24-40 | 40 | 29.0 | 5.5 | 4.2 | 0.7 | 0.85-0.5 | 28×3.55 |
| JD-24-45 | 45 | 34.0 | 33.5×3.55 | ||||
| JD-24-50 | 50 | 39.0 | 38.7×3.55 | ||||
| JD-24-55 | 55 | 44.0 | 43.7×3.55 | ||||
| JD-24-60 | 60 | 49.0 | 47.5×3.55 | ||||
| JD-24-63 | 63 | 52.0 | 50×3.55 | ||||
| JD-24-65 | 65 | 54.0 | 53×3.55 | ||||
| JD-24-70 | 70 | 59.0 | 58×3.55 | ||||
| JD-24-75 | 75 | 64.0 | 63×3.55 | ||||
| JD-24-80 | 80 | 64.5 | 7.75 | 6.3 | 1.2 | 1-0.6 | 63×5.3 |
| JD-24-85 | 85 | 69.5 | 69×5.3 | ||||
| JD-24-90 | 90 | 74.5 | 73×5.3 | ||||
| JD-24-100 | 100 | 84.5 | 82.5×5.3 | ||||
| JD-24-110 | 110 | 94.5 | 92.5×5.3 | ||||
| JD-24-120 | 120 | 104.5 | 103×5.3 | ||||
| JD-24-125 | 125 | 109.5 | 109×5.3 | ||||
| JD-24-130 | 130 | 114.5 | 112×5.3 | ||||
| JD-24-140 | 140 | 124.5 | 122×5.3 | ||||
| JD-24-140A | 140 | 119 | 10.5 | 8.1 | 1.5 | 1.25-0.6 | 115×7 |
| JD-24-150 | 150 | 129 | 128×7 | ||||
| JD-24-160 | 160 | 139 | 136×7 | ||||
| JD-24-170 | 170 | 149 | 145×7 | ||||
| JD-24-180 | 180 | 159 | 155×7 | ||||
| JD-24-190 | 190 | 169 | 165×7 | ||||
| JD-24-200 | 200 | 179 | 175×7 | ||||
